8 Pixel Lamp CREE RGBW LED Stage Lighting For Live Concerts / TV Studios

8 Pixel  XLamp CREE RGBW LED for Medium Live Concerts / TV Studios

Quick Detail:

The MSPY 4810F, with infinite (continuous) PAN movement, is designed with four parallel heads that could punch with 2 outstanding sharp beams by each head which is controllable with TILT projection angles (0°-90°) . It’s a fixture producing high light output. Each LED is a pixel available for control independently, not only speed but also saturated linear dimmer. It offers 10 internal
programs and default macro functions for easy control and performance in a rather simple way. The moving could also creates an amazing streaming effect by professional programming. It’s a simple system, easy for installation with two 1/4 turn fastening Omega Clamps. The MSPY 4810F is available for small to medium live concerts, TV studios, video productions, road shows, mobile DJ, clubs, disco, etc.

Description:

​

1. 8PCS 8W cool white LEDs for SI-103                                                                                     8PCS CREE XLamp XML 4-IN-1 10W LEDs for SI-103F
2. 50,000 hours lifespan and low power consumption
3. 8 pixels (each LED is a pixel), controllable individually
4. Outstanding sharp BEAM effect
5. Specific optic system
6. Infinite (continuous) PAN movement
7. 4 parallel heads with TILT projection angles adjustable
8. independently (0°-90°)
9. High efficiency LED shutter
10. High speed strobe effect with 1-25 flashes per second
11. 0-100% smooth linear LED dimmer
12. Amazing streaming effect by pro control
13. 10 Internal program available
14. Default pixel macros effect for easy performance
15. 26/13/26 DMX Channels USITT DMX-512 (including
16. design mode) for SI-103
17. 50/15/50 DMX Channels USITT DMX-512 (including
18. design mode) for SI-103F
19. DMX512, master-slave and sound activated controllable
20. or auto operation
21. High definition blue LCD display
22. Efficient low noise fan cooling system
23. POWERCON IN/OUT
24. 3-pin XLR connectors IN/OUT
25. Constant temperature readout and management function
26. DB rating@1M=54.18dB
27. IP20 protection rating
28. -35°C to 45°C ambient temperature
29. 2*1/4 turn fastening Omega Clamps
30. 1* Safety attachment point

Applications:

Disco and Club

Live performance

Stage show

Specifications :

• Input Voltage: AC90-260V 50/60Hz
• LED Quantities: 8PCS 8W white LEDs for SI-103
• 8PCS CREE XLamp XML 4-IN-1 10W LEDs for SI-103F
• Control Signal: DMX512,master-slave and sound activated or auto operation
• Control Channel: 26/13/26 DMX Channels USITT DMX-512 for SI-103
• 50/15/50 DMX Channels USITT DMX-512 for SI-103F
• Power Consumption: 75W for SI-103 99W for SI-103F
• Dimensions: 280(D)*405(W)*260(H)mm
• Packing Dimensions: 380(D)*505(W)*400(H)mm
• Net Weight: 9kg
• Gross Weight: 12kg

Competitive advantages:

good price, reliable quality, guarantee of delivery,good after service
